Frsky R-XSR receiver with telemetry (ACCST / ACCESS)

Description

FrSky R-XSR  receiver is the evolution of FrSky full range XSR receiver. The R-XSR is a standalone receiver with all the functions of XSR, in addition, it’s almost 1/3 size and 1/3 weight of XSR receiver. Moreover, there redundancy function is integrated into this tiny receiver ensures the security, and the IPEX connector makes it more convenient for you to replace antennas. Telemetry is supported via F-Port.

NOTE: R-XSR supports either ACCST S.Port, ACCST F.Port or ACCESS mode via firmware flashing. Please select the correct version and we will flash the correct firmware for you.

• ACCST S.Port: If you are using multi-protocol Radio Controller and need support for S.Port telemetry sensors. Telemetry is using S.Port protocol on S.Port pin and receiver signals are on SBUS pin.
• ACCST F.Port: If you are using multi-protocol Radio Controller and want to use telemetry with flybarless controllers like MSH Brain2, Spirit or RotorFlight. Telemetry and receiver signals are on S.Port pin using F.Port protocol.
• ACCESS version: If you are using Latest Frsky Radios with ACCESS support. Telemetry can be supported via S.Port or F.Port protocol. Can be selected at the Radio Controller.

Redundancy Function

• R-XSR supports the redundancy function for the master and slave receivers. The master receiver receives SBUS signal from the slave receiver. The master receiver can be R-XSR, and the slave receiver can be receiver with SBUS output (for example, FrSky X8R, XM+, etc).
• Note: Make sure telemetry is disabled on the slave receiver when the slave receiver is FrSky X series receiver. XM+ is recommended as the slave receiver.

Features

• Ultra mini size and light weight
• Support telemetry and Smart Port / F.port enabled
• Full range
• Switchable SBUS/ CPPM signal output
• Supports redundancy function
• IPEX connector, replaceable antennas

Specifications

• Number of channels: 16CH (1-16CH from SBUS channel, 1~8CH from CPPM channel)
• Operating Voltage Range: 3.5V~10V
• Operating Current:70mA@5V
• Firmware Upgradable
• Compatibility: ACCST D16 / ACCESS mode
• Dimension: 16*11*5.4mm (L*W*H)
• Weight: 1.5g

Includes

• R-XSR Receiver with 2 antennae
• 5-pin JST to JR/Servo connector cable
• 5-pin JST to 5-wire cable
• Instruction sheet
• Heat shrink tubing (OriginHobbies only)

Downloads

• R-XSR User Manual (ACCST/D16 mode)
• R-XSR User Manual (ACCESS mode)
