SAB ILGoblin COMPETIZIONE – SG779 #59

Beschreibung

ILGoblin COMPETIZIONE #59 represents the ultimate racing machine born from years of competitive experience and rigorous testing with the world’s elite Goblin pilots. Engineered with a “zero-compromise” philosophy, every single solution is focused on achieving peak performance.

In competition flying, lightweight is everything. Despite its ability to handle extreme power and aggressive maneuvers, the ilGoblin Competizione maintains a remarkable airframe weight of under 2 kg.

Experience a level of acrobatic precision and flight feel never achieved before.

Features

Spezifikationen

• Airframe weight: 1990 g (no blades, no battery, no electronics)
• Main rotor diameter: 1576 mm (with 700 mm blades)
• Main blade length: 650–730 mm
• Tail rotor diameter: 292 mm (with 110 mm tail blades)
• Tail blade length: 105–115 mm
• Servos: Standard size (40 mm) for Cyclic and Tail
• Main rotor ratio: 11.8 to 8.8 : 1 (21T pulley included = 10.1 : 1)
• Tail rotor ratio: 5.1–4.9 : 1 (26T pulley included = 4.9 : 1)
• Power system: 6S–12S setups (Motor KV: 480–560 / 950–1100 KV)
• Battery compartment: 50 x 60 x 300 mm

Kit Includes:

• 22T motor pulley
• 26T tail pulley
• 2 battery trays
• S702 Yellow main blades (700 mm)
• S110 Yellow tail blades (110 mm).

Recommended Components

• Motor: Scorpion HK5-4525-535kV / Scorpion HK5-5024-535kV
  Xnova Lightning 4535-530kv, Xnova Lightning 4530-525kV
• ESC: Scorpion Tribunus III 14-220A HV
• 3x Cyclic Servos: KST BLS915 V8 HV
• Tail Servo:  KST BLS905X V2 HV
• Batterie:
  • Gens ace 5000mAh 60C 12S1P x1
  • Gens Ace 5600mAh 80C 12S1P x1
  • Gens ace 5000mAh 45C 6S1P x2
  • Gens ace Sport 5600mAh 80C 6S1P x2

Downloads

• ILGoblin COMPETIZIONE User Manual SG779 #59
